High Speed 3 Lines T-Shirt Bag Making Machine With Hot Slitting and Side Gusseting Unit

Classification: Machine de scellage et découpage

MING JILEE ENTERPRISE CO., LTD.

Pays: Taïwan

Téléphone: 886-6-5783420

Fax: 886-6-5783347

Personne de contact: Chris Chang

Enquête maintenant

The MGA-TS-360-G3 is Ming Jilee's high speed 3-line T-shirt bag making machine, built with a hot slitting station and a side gusseting unit so all three lanes cut, seal and gusset bags in one synchronized pass.

It handles bag lengths of 350 - 650 mm and bag widths of 160 - 365 mm, running film at 0.008 - 0.05 mm thickness / layer at 160-220 cycles/min/line per lane, powered by an 8 kw heater on a 220V, 3Phases, 50 / 60 HZ, 25KVA supply. The machine has a footprint of 972 x 225 x 212 cm at a net weight of 5,000 kg.

Model

MGA-TS-360-G3

Bag Lenght	350 - 650 mm	Dimensions (L x W x H)	972 x 225 x 212 cm
Bag Width	160 - 365 mm	Net Weight	5,000 kg
Bag Thinkness / Layer	0.008 - 0.05 mm	Gross Weight	5,600 kg
Speed / Cycle / min / line	160-220	Packing (L x W x H)	Unwinder 170 x 221 x 140 cm
Heater	8 kw		Gusset unit 318 x 227 x 220 cm
Power	220V. 3Phases, 50 / 60 HZ, 25KVA		Punch 264 x 206 x 170 cm
