All-Electric Two-Component Injection Molding Machine (CT-R series)
Introduction All-Electric Two-Component injection molding equipment which is suitable for two-component and multi-component products, including electronic parts, medical appliance, cosmetic containers, etc. With its clamping force ranging from 180 tons to 400 tons. Features Adopting multiple independent barrels for parallel injection, greatly shortens the cycletime. The injection carriage is equipped with linear guides and has low charging back pressure, reducing melt overflow. The servo rotary table speed is improved by 30%-50%, which shortens the cycle time and enables fast and smooth speed switching. The servo rotary table switches rotating direction with positioning accuracy up to 0.005°, making injection molding products more precise and stable. Tie bars are not embedded in platen to reduce pollution, abrasion and power consumption, which is suitable for medical and electronic parts. Intelligent mold clamp low-pressure protection, reduces the risk of mold crush. The whole machine is controlled by servo motors, all the movement is fast and stable. Compared with hydraulic machine, it saves electricity by 70-40%. With high-speed production and multi-axis synchronous control, it provides customers with the shortest cycle time design, and the stability of the weight of the molded product is within 0.3%. Support OPCUA agreement, can be integrated with iMF 4.0 smart management system, provide differentiated services.
